16040
16040
model 16040
Metering system Metric system
Bearing Type Ball
Load Direction Radial
Structure Single Column
Seal Type Open
Inside Diameter 200 mm
Inner Diameter Tolerance -0.022mm to 0
Outer Diameter 310 mm
Outer Diameter Tolerance -0.025mm to 0
Width 34 mm
Width Tolerance -0.3mm to 0
Ferrule Material 51200 Chrome steel
Ball Material 51200 Chrome steel
Dynamic Radial Load 37768 lbf
Static Radial Load 42714 lbf
Max Speed(X1000 rpm) 2.8
Lubricant None
Temperature Range -30° to 120 °C
ABEC Standard P6
Radial Inner Clearance CN
RoHS Standard Conform
REACH Standard Conform
Weight 8780 g
