217 - Single Row Deep Groove Ball Bearings With Gilled Grooves - Shandong Zhio bearing Technology Co., LTD

model	217
Metering system	Metric system
Bearing Type	Ball
Load Direction	Radial
Structure	Single Column
Seal Type	Open
Inside Diameter	85 mm
Inner Diameter Tolerance	-0.02mm to 0
Outer Diameter	150 mm
Outer Diameter Tolerance	-0.018mm to 0
Width	28 mm
Width Tolerance	-0.2mm to 0
Ferrule Material	51200 Chrome steel
Ball Material	51200 Chrome steel
Cage Material	Nylon
Positioning features bearing outer ring	None
Dynamic Radial Load	21762 lbf
Static Radial Load	22481 lbf
Max Speed(X1000 rpm)	4.8
Lubricant	None
Temperature Range	-30° to 120 °C
ABEC Standard	P0
Radial Inner Clearance	CN
RoHS Standard	Conform
REACH Standard	Conform
Weight	1.95 kg
